Information
Fitted their montage models with a stroke of genius the super knob. This appropriately named controllets you execute one-hand dynamic sound modifications, from subtle to severe. With the Super Knob you can control multiple parameters at once. You can, for instance, change the ambient perspective of an instrument or a vocal, shooting it from in your-face to deep inside a cave, and then back again
|
Specifications
Weight |
17000 Gram |
Lebar |
1.244mm (49") |
Tinggi |
131mm (5 - 3/16") |
Kedalaman |
396mm (15 - 9/16") |
Jumlah Kunci |
76 |
Tipe |
FSX Keyboard |
Sentuhan Awal |
Yes |
After Touch |
Yes |
Tone Generator |
Motion Control Synthesis Engine AMW2: 8 Elements FM-X: 8 Operators, 88 Algorithms |
Polyphony Maksimal |
AWM2: 128 (max: stereo/mono waveform) FM-X: 128 (max) |
Kapasitas Multi Timbral |
16 parts (internal), Audio Input Parts (A/D*, *USB) *stereo part |
Gelombang |
Preset: 5.67 GB (when converted to 16 bit linear format), User: 1.75GB |
Penampilan |
Approx 1.900 |
Penyaring |
18 types |
Efek |
Reverb x 12 types, Variation x 76 types, Insertion (A, B) x 76 types*, Master Effect x 15 types *A/D part insertion x 71 types (Preset settings for parameters of each effect type are provided as templates) Master EQ (5 bands), 1st part EQ (3 bands), 2nd part EQ (2 bands) |
Pengatur |
Master Volume, AD Input Gain knob, Pitch Bned wheel, Modulation wheel, Ribbon Controller, Control Sliders x 8, Knobs x 8, Super Knob, Data Dial |
Tampilan |
7" TFT Color Wide VGA LCD touch screen |
Sambungan |
[USB TO DEVICE], [USB TO HOST], MIDI [IN]/[OUT]/[THRU], FOOT CONTROLLER [1]/[2], FOOT SWITCH [ASSIGNABLE]/[SUSTAIN], OUTPUT (BALANCED) [L/MONO]/[R] (6,3mm Balanced TRS jacks), ASSIGNABLE OUTPUT (BALANCED) [L]/[R] (6,3mm Balanced TRS jacks), [PHONES] (6,3mm standard stereo phone jack) A/D INPUT [L/MONO]/[R] (6,3mm standard phone jacks) |
Penggunaan Daya |
27 W |
Live Sets |
Preset: 128 and more, User: 2.048 |
Tracks |
16 sequence tracks, Tempo tracks, Scene tracks |
Recording type |
Real time replace, Real time overdub, Real time punch in/out |
Note Capacity |
Approx 130.000 notes |
Note Resolution |
480 ppq (parts per quarter note) |
Tempo (BPM) |
5 – 300 |
Songs |
64 songs |
Arpeggio |
Parts: 8 Parts simultaneous (max.), Preset: Approx. 10,000 types User: 256 types |
Sequence formats |
MONTAGE original format, SMF formats 0, 1 |
|
